Cycle time 15% down (compared to previous model)
※ Data taken while running machining program created by our company. |
 |
 Reduced tool change time
Tool change time is greatly reduced by increasing the arm’s swivel speed and reducing any waste time. |
| Tool to Tool |
|
Chip to Chip |
| Previous model |
→ |
TC-20B |
|
Previous model |
→ |
TC-20B |
| 0.8sec |
0.4sec(When using small tool) |
1.6sec |
1.1sec(When using small tool) |
|
| |
|
 |
Improved acceleration
Acceleration of the Z-axis during frequent operation is dramatically improved. In addition to this, vibration is reduced via vibration control. |
| Z-axis acceleration |
| Previous model |
→ |
TC-20B |
| 1.1G |
2.5G(최대) |
|
| |
|
| Heat expansion compensation system II |
 |
| |
This system predicts the heat expansion based on the movement of each axis and compensates for it. A no sensors are used, machining time is not affected.
※ External factors, such as coolant temperature and ambient temperature, are not considered. Accuracy may be affected under some conditions. |
